Video Formats

(4K) 4096 x 2160p、(UHD) 3840 x 2160p、(2K) 2048 x 1080p、(HD) 1920 x 1080p、(HD) 1920 x 1080i、(HD) 1280 x 720p、(SD) 720 x 576i、(SD) 720 x 480i

12G-SDI

Video Input

·1x 12G-SDI BNC, SMPTE-259/292/424/2081/2082

·YCbCr 4:2:2/4:4:4

·RGB 4:4:4,

·10-bit

12G-SDI

Video Resolution

·1x 12 Gb SDI

(4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

(UHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

·1x 6 Gb SDI

(4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30

(UHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30

·1x 3 Gb SDI

(HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

(HD) 1920 x 1080i 50, 59.94, 60

(HD) 1280 x 720p* 50, 59.94, 60

·1x 1.5 Gb SDI

(HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30

(HD) 1920 x 1080i 50, 59.94, 60

(HD) 1280 x 720p 30,50, 59.94, 60

·1x 270 Mb SDI

(SD) 625i 50

(SD) 525i 59.94

12G-SDI

Optical Input

1x 12G-SDI fiberLC connector，SMPTE 297/259/292/424/2081/2082
·Nominal Wavelength:Rx 1260 nm (Min)， 1620 nm (Max)
·Optical Sensitivity: - 10dbm(Min12gbps)， - 14dbm(Min3gbps)

12G-SDI

Optical Output

1x 12G-SDIfiber LC connector, SMPTE259/292/424/2081/2082

Nominal Wavelength：Tx 1260 nm（Min）、1310 nm（TYP）、1620 nm（Max）（CWDM wavelength optional）

Optical Power：-5 dBm（Min），0.5 dBm（Max）

HDMI

Video Output

·1x HDMI Type A connector，HDMI V2.0

·HDR signaling metadata pass-through and optional override;

·YCbCr 4:2:2/4:4:4/4:2:0

·RGB 4:4:4, SMPTE or Full level

·8 or 10-bit (HFR 4K/UltraHD 4:4:4 limited to 8-bit)

HDMI

Output Resolution

(4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

·(UHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

·(HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

·(HD) 1920 x 1080i 50, 59.94, 60

·(HD) 1280 x 720p 30,50, 59.94, 60

·(SD) 720 x 576i 50

·(SD) 720 x 480i 59.94

Audio

Pass-Through Formats

· PCM
·Dolby Digital(AC-3)

AudioOutput Digital

·SDI embedded audio, 24-bit (SD limited to 20-bit), 16-channel

AudioOutput Digital

·HDMI embedded audio, 24-bit, 8-channel

Audio Output Analog

· 2x RCA style connector, 2-channel -10dBu (nominal)

Size (w x d x h)

(105 x 92x 29 mm)

Weight

(0.3 kg)

Power

12V DC，10W
100-240V AC, 50/ 60hz

Environment

Safe Operating Temperature：0 to40℃
Safe Storage Temperature (Power OFF)：-40 to60℃
Operating Relative Humidity：10-90% noncondensing
